Winter rebuild project

So, I've got my winter project under way. Doing a full rebuild of the engine because I had to replace the balance dampers. Figured while I was at it, to change the old sty shift rod for the stronger one. And while I'm doing all that I figured a good cleaning of the heads, new oil seals, and possible valve lapping weren't a bad idea. Going to through in some new piston rings and a fresh cylinder honing in while I'm at it too.

Tear down started


It's amazing how easy it is to get the engine out of the frame when you can just lift the frame away


Case split open on the table


parts stashed on the bench


Started repainting a few of the engine parts.... Before:


...After


Decided to try something differant with the he oil level sight lines.

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
Sponsored Links
Advertisement

post #2 of 22 (permalink) Old 01-10-2014, 10:17 AM
Jack of all trades

M_Angell's Avatar

Join Date: Jul 2009
Location: Westland, Michigan
Posts: 2,863
iTrader: (11)

Nice. Looks brand new and shiny.

2003 vn750
1988 Pontiac Trans Am (project/driver)
M_Angell is offline
post #3 of 22 (permalink) Old 01-10-2014, 10:23 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Thing on the to do list for the project:
  • Rebuild the engine
  • Powder coat the frame. --I'd love to get it done in a black chrome. have to check around on prices and if anyone local can even do it.
  • New larger headlight housing. (as seen in photo #1 above) I'm planning on going with one of the LED Kurry Phase 7 lights.
  • New light bar with 4.5" driving lights (also Kurry LED Phase 7) and turn signals mounted to the bar.
  • Repaint the tank and fenders. Undecided on the color yet
  • New Single gauge cluster to replace all of the original gauges and indicator lights (need to refind the link for it...)

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline

post #4 of 22 (permalink) Old 01-10-2014, 10:26 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Quote:
Originally Posted by M_Angell View Post
Nice. Looks brand new and shiny.
I just hope the paint holds up. Heat wise should be fine, I'm just worried about any gas that might splash onto it. Rustoleum claims its gas and oil resistant, we shall see...

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
post #5 of 22 (permalink) Old 01-10-2014, 01:01 PM
Sparky!!!

slimvulcanrider's Avatar

Join Date: May 2008
Posts: 8,695
iTrader: (3)

Garage
Quote:
Originally Posted by Ndr View Post
I just hope the paint holds up. Heat wise should be fine, I'm just worried about any gas that might splash onto it. Rustoleum claims its gas and oil resistant, we shall see...
for what you are doing you should be fine... the problem comes from spilling gas directly onto the paint, and gas fumes bubbling from the inside out
slimvulcanrider is offline
post #6 of 22 (permalink) Old 01-11-2014, 07:45 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Quote:
Originally Posted by slimvulcanrider View Post
for what you are doing you should be fine... the problem comes from spilling gas directly onto the paint, and gas fumes bubbling from the inside out
Cool, thanks.

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
post #7 of 22 (permalink) Old 01-11-2014, 08:18 AM
Dr. Vulcanstein

jadabull's Avatar

Join Date: Apr 2013
Location: florida
Posts: 1,536
iTrader: (6)

Quote:
Originally Posted by Ndr View Post
Cool, thanks.
Duplicolor makes a great heat/corrosion resistant paint.


.... - " " - .
..( ___/\ /))
.( l vv/ )(
.) \ O/ )((
..(( .)(. )\ \
.....) . ( / /
.....( )
jadabull is offline
post #8 of 22 (permalink) Old 01-28-2014, 11:47 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Got the motor finished, spins over by hand. Here's hopping is fires up once I finally get to put it back on the frame...


Started stripping the frame. Bought the Klen-Strip Aircraft paint remover. This stuff works pretty damn good. Found out the hard way though that the golves I have don't stand up to it. oops...
http://www.pepboys.com/product/detai...99/?quantity=1


after 30 minutes of work (including spay and wait)

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)

Last edited by Ndr; 02-06-2014 at 12:50 AM. Reason: Fixed IMG link
Ndr is offline
post #9 of 22 (permalink) Old 01-28-2014, 12:02 PM
..have a vulcan good day!

WilliamTech's Avatar

Join Date: May 2011
Location: Pensacola, FL.
Posts: 4,508
iTrader: (17)

I have always had this thought.....

Is it possible ....to anchor the engine in some way, and with a Battery, Starter Solenoid, cables/wires, and hanging a temporary (2 liter bottle ?) fuel supply

to fire an engine up prior to bike installation ?

Has anybody attempted this ?

Sure would be nice....enable additional carb tweaking/jet changing easy.


'86 VN750 13,700 mi -Stock
-Purchased 2008 w/8800mi
Replaced ALL Cables . Kuryakyn LED Voltmeter
SilverStar Ultra 9003/HB2 H4 Headlamp, Jardine Fwd Controls,
Iridiums DPR7EIX-9 & Wires, Tuxedo Mod, Coil Mod, P/U Sensor Mod, Fork Seals,
Splines Lubed - 11/4/2012 - MF AGM Battery
Additional Flashing LED Brake Light on Trunk
Dampers went out @ 13+K !
After TOC MCCT's..... so amazingly quiet I discovered a rattling heat shield on my stock exhaust !
...have a vulcan good day!

Last edited by WilliamTech; 01-28-2014 at 12:05 PM.
WilliamTech is offline
post #10 of 22 (permalink) Old 01-28-2014, 12:52 PM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Quote:
Originally Posted by WilliamTech View Post
I have always had this thought.....

Is it possible ....to anchor the engine in some way, and with a Battery, Starter Solenoid, cables/wires, and hanging a temporary (2 liter bottle ?) fuel supply

to fire an engine up prior to bike installation ?

Has anybody attempted this ?

Sure would be nice....enable additional carb tweaking/jet changing easy.

It's certainly possible. The real question is if its a good idea. WOuld be nice to know sooner than later if the engine was working properly.

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
