Coolant Drains

Can anyone tell me if there is anything supposed to be plugging this hole? Or something attached to it?

I don't recall taking any bolts out from here, never-mind that there aren't even any threads to accept a bolt in the first place.

The channel leads straight into the center hub where the bearings sit. Looks like it would come out between the front of the bearing and the back of the mechanical seal.

I'm thinking that if the Oil seal behind the inner bearing, and the mechanical seal are doing their jobs, no fluid should be getting in this area.

the thing was completely blocked up with dirt and grit.


......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
Sponsored Links
Advertisement

post #2 of 17 (permalink) Old 01-11-2014, 09:26 AM
Senior Member

jeankawa's Avatar

Join Date: Nov 2012
Location: chelsea, qc
Posts: 100
iTrader: (1)

hi, there is no plug or bolt there, mine has an empty hole like yours.
jeankawa is offline
post #3 of 17 (permalink) Old 01-11-2014, 09:31 AM
Dr. Vulcanstein

jadabull's Avatar

Join Date: Apr 2013
Location: florida
Posts: 1,536
iTrader: (6)

that is a weep hole in case your mechanical seal goes bad.


.... - " " - .
..( ___/\ /))
.( l vv/ )(
.) \ O/ )((
..(( .)(. )\ \
.....) . ( / /
.....( )
jadabull is offline

post #4 of 17 (permalink) Old 01-11-2014, 12:03 PM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Thanks guys, that's kinda what I was thinking, but wanted to be 100% sure.

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
post #5 of 17 (permalink) Old 01-11-2014, 12:44 PM
Member

Join Date: Jun 2013
Posts: 70
iTrader: (0)

I've always wondered about this myself. Good question, good pictures, good post.
Tuvoc is offline
post #6 of 17 (permalink) Old 01-11-2014, 02:52 PM
ass hole extaordinaire

new rider 9984's Avatar

Join Date: May 2012
Location: Sulphur Springs TX
Posts: 3,780
iTrader: (7)

what ever you do if it ever starts leaking do not stick a dowl rod in it like some idiot did on my dads gl1200 cause it will just push the coolant into the oil instead of out on the ground

Quote:
Originally Posted by denny6006 View Post
Sucks getting old but it beats not getting old.

i got my helmet but it sure makes licking the windows a chore

cell phone number for anyone who needs it 214-516-1738

photobucket link
http://s1066.photobucket.com/user/newrider9984/library/
new rider 9984 is offline
post #7 of 17 (permalink) Old 01-11-2014, 03:36 PM
FREEBIRDS MC CENTRAL NY

OleDirtyDoc's Avatar

Join Date: May 2011
Location: Norwich,NY
Posts: 16,039
iTrader: (0)

Garage
Send a message via Yahoo to OleDirtyDoc
My .gl1000 is leaking out the weep hole.gotta do waterpump.haven't ridden her in 2 years cause they are fun to do a waterpump on.

Sent from Motorcycle.com Free App

ONE RATS ASS GIVEN PER POST
Support your local FREEBIRDS MC
1986/5 Vn700/750 Frankenfook cross eyed bitch "Mellisa Fayhe"
I am a BIKER and i'm proud.FREEBIRDS MC CENTRAL NY

lowered with progessive 412 10" shocks
rejetted for K/N Pods part#rc 2340
sportster seat

'I didn't lose my mind.i gave it away

BRING BACK WOLFIE."Peace and Carrots"RIP
"And I'm free...as a bird"John Lennon Free as a Bird
"I only carry when I have my pants on"Joe Robinson RIP aka Old Dog
OleDirtyDoc is offline
post #8 of 17 (permalink) Old 01-11-2014, 04:13 PM
ass hole extaordinaire

new rider 9984's Avatar

Join Date: May 2012
Location: Sulphur Springs TX
Posts: 3,780
iTrader: (7)

they arent that bad just pull the radiator off and then the trans cover and wah laa your there

Quote:
Originally Posted by denny6006 View Post
Sucks getting old but it beats not getting old.

i got my helmet but it sure makes licking the windows a chore

cell phone number for anyone who needs it 214-516-1738

photobucket link
http://s1066.photobucket.com/user/newrider9984/library/
new rider 9984 is offline
post #9 of 17 (permalink) Old 01-15-2014, 03:32 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

Quote:
Originally Posted by new rider 9984 View Post
what ever you do if it ever starts leaking do not stick a dowl rod in it like some idiot did on my dads gl1200 cause it will just push the coolant into the oil instead of out on the ground
With as much dirt that I pulled out of that weep hole, it may as well have been plugged up with a dowel rod...

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
post #10 of 17 (permalink) Old 01-15-2014, 03:44 AM Thread Starter
Ndr
Senior Member

Join Date: Feb 2010
Location: Pittsburgh, PA
Posts: 856
iTrader: (10)

And along the lines of the cooling system...

I've been wondering about the whole concept of the radiator fan keeping power after turning the engine off. (too cool things off for up to a minute after the engine is off?)

Is this really doing anything for cooling the engine itself, or is it only cooling down whats in the radiator? I assume that there's no auxiliary pump circulating the water through the engine at this point.

In my opinion, I see this as nothing more then a potential drain on the battery given the potential for draining the battery more then is necessary. (especially if the switch fails and grounds itself out keeping the fan on)

I know several on here with bad switches has mounted toggle switches to control the fan when needed.

Would it then be a bad a idea to rewire the system to only have power with the ignition turned on, thereby not allowing the fan to cool the radiator once the power is cut?

......I'd rather wake up in the middle of nowhere then in any city on earth.

*2014 VN900 Custom (16,200 miles and counting)
Ndr is offline
