2002 meanstreak build

I have not been on in a while and have not keeped you guys informed on my project and I appologize. About three months ago I purchases a 2002 kawi MeanStreak 1500 whit a spun rod for 600 dollars. I know your guys are thinking "what is the catch and or who did you rip off?". Well it cam in 6 tuper ware boxes. The previous owner had disasembled it left on his bench for a couple years and never did anything else with it.



It cost me 800 dollars to get the crank fixed and rods cliped. I was not suppose to cost this much but Kawi over hardened the crank so it would not take chrome. It would just peal off when the machined it, so it had to be welded. It seems simple and normally can be for a competant machinist, but on single journal cranks it is a night mare. you can only weld about and inch on a certain spot with cause the crank to draw together, so then you have to weld the other side to draw it back as well as multiple trips to the oven to keep the hardness. this whole process took about 3 week from when I droped it off. atleast I had some time to get the money together lol.



I wish I had taken pictures of the crank before and after. I was just tired and agrevatted when I did the lower end. I had put the crank in backwards and did not notice till I had placed sealant and torqued the whole block.



These components took some serious torque to tighten down to spec. you would believe how heavy this thing is. you could seariously pop a testicle lifting it.



I spent alot of time scratching my head wondering why timeing would reproduce after turning it over. Duh I was was turining it over backwards unloading the timing chains lol. I need to find some pictures of the pistons. They were a mess because the owner left them on the bench and scratched them all to hell as well as bearing particles being embeded. My machinist convinced me not to buy new pistons but take scotch bright and sand the sides till smoth with a corass hatch and once dont measure the piston in various places to compare to the specs and decide wether to have them coated or not. luckily the were still in spec when I finished. less money invested the better.



I do not know how I would have gotten this engine in by my self with out my motorcyle jack.



currently were I stand is trying to do up a paint job for it. I purchased a damaged kawi sport bike tank so I could weld in the gas cap for a flush look since this bike will have the dash deleted. it has been a long time since I have put down flames so I was practicing with some old spray paint. My stripe tapes is about 9 years old lol. it did not want to lay down very good.

Harley sportster fenders
custom raked front end
custom exhaust
vn800 tank and guages
modified seat and recovered
rear frame chopped
custom wiring harness
airbox removed
hzhardy is offline
Sponsored Links
Advertisement

post #2 of 7 (permalink) Old 07-11-2012, 06:19 PM
Sparky!!!

slimvulcanrider's Avatar

Join Date: May 2008
Posts: 8,696
iTrader: (3)

Garage
ohh hells ya.. keep them updates and pics coming.. you are always throwin together some wicked ride
slimvulcanrider is offline
post #3 of 7 (permalink) Old 07-11-2012, 06:36 PM Thread Starter
Senior Member

Join Date: Mar 2010
Location: jacksonville, fl
Posts: 335
iTrader: (1)

I still need to finish my 750 lol, i have just been way to busy doing other peoples stuff.

Harley sportster fenders
custom raked front end
custom exhaust
vn800 tank and guages
modified seat and recovered
rear frame chopped
custom wiring harness
airbox removed
hzhardy is offline

post #4 of 7 (permalink) Old 07-12-2012, 10:44 PM Thread Starter
Senior Member

Join Date: Mar 2010
Location: jacksonville, fl
Posts: 335
iTrader: (1)

Damn slim I do not think anyone cares about a mean streak build lol.

Harley sportster fenders
custom raked front end
custom exhaust
vn800 tank and guages
modified seat and recovered
rear frame chopped
custom wiring harness
airbox removed
hzhardy is offline
post #5 of 7 (permalink) Old 07-13-2012, 01:00 AM
1986 VN750

thtanner's Avatar

Join Date: Nov 2011
Location: Dana Point, CA
Posts: 3,255
iTrader: (8)

Garage
Quote:
Originally Posted by hzhardy View Post
Damn slim I do not think anyone cares about a mean streak build lol.
I'm just quietly awaiting more pics :P

1986 Kawasaki Vulcan 750
NGK Iridium Plugs #7803/DPR7EIX-9
Duralast Gold ETX15 AGM Battery
Coastered & Shaved
TOC MCCTs
Metzeler ME880 [110/90-19, 170/80-15]
Balance Dampers Replaced
Tuxedo Mod
Rebuilt Forks w/ Progressive Springs
V&H Cruzers
VN750.com Grill Cover
Meanstreak Seat
Emgo 23-92411 Handlebars
MOSFET FH012AA R/R


1990 Kawasaki Vulcan 750

1998 Honda VFR800 FI

2014 Honda VFR800F

1989 Pontiac Firebird Formula 350
thtanner is offline
post #6 of 7 (permalink) Old 07-13-2012, 11:33 AM Thread Starter
Senior Member

Join Date: Mar 2010
Location: jacksonville, fl
Posts: 335
iTrader: (1)

I hope to prep the tank up in the next couple weeks. It is full of gas right no, so I need to get it all out then dunk the tank in water before I weld on it. If not I will ruin a perfectly good meany tank and be hurting lol. I am debating on what to do about the overflow drain. I am thinking about taking the ninja filler piece and cutting it below the filler mounts (after i remove the mount on the meany) and see if i can't get it to slide in with a bit of force with out haveing to cut the tank open. I even thought about useing a rubber hose to conect the two pipe, but if it rots your screwed, or just get rid of the over flow all together and keep a rag handy if you spill fuel in the recess. Ramble off

Harley sportster fenders
custom raked front end
custom exhaust
vn800 tank and guages
modified seat and recovered
rear frame chopped
custom wiring harness
airbox removed

Last edited by hzhardy; 07-13-2012 at 01:20 PM.
hzhardy is offline
post #7 of 7 (permalink) Old 07-18-2012, 04:50 AM
Senior Member

Join Date: Apr 2012
Location: Central Illinois
Posts: 114
iTrader: (0)

Every time I trip across a picture of a meanstreak I always look over my shoulder, as if I were viewing porn or something.
Good on you for not letting it sit there and rot. I'm sure it will be worth the money and effort.
