battery problem and spark plug wire

I have not had my 750 long and I'm starting to have some starting problems. I'm not sure if it's the battery or a charging issue. The bike cranks slow and if it does not start the 1st few times I have to jump it. The last owner said he put a new battery in last spring and he did not ride it over the winter but a time or two.
I checked all of the connections and had a loose ground, got that fixed and it did not help. I tried to get the battery tested but they said it was not charged enough to test (should I put it on a charger then bring it up there?)

I will be thankful for any and all help!

Last edited by slowz; 04-25-2011 at 09:11 PM.
slowz is offline
Sponsored Links
Advertisement

post #2 of 9 (permalink) Old 04-18-2011, 09:10 PM Thread Starter
Junior Member

Join Date: Apr 2011
Location: Foley AL
Posts: 20
iTrader: (0)

Btw when I do jump it off the bike starts right up the 1st crank , not sure if that matters or not
slowz is offline
post #3 of 9 (permalink) Old 04-18-2011, 09:19 PM
Patriot Guard Rider

The DEUCE's Avatar

Join Date: Jan 2011
Location: Torrance, CA
Posts: 825
iTrader: (20)

Sounds like you need a new Maintenance Free Gel Cell Battery.

1986 Black Kawasaki Vulcan VN750 "Black KAWK"
VN750 #9300 & VROC #33453

EMGO Handlebar, V&H Exhaust, Drop Shocks, Raised/Painted Fork, MeanStreak Seat, Tank Bib, ME880 Oversize Tires, Engine Guard, Custom Mirrors, Chris Products Turn Signals, Ear Shave, 150/42 Jets, PINGEL Fuel Valve, MCCT, Volt Meter, Shendegen R/R, AGM Battery, Coastered, .020 Coils, Relo Gauges & Headlamp, SilverStar Ultra, LED Flashing Brake Light, Center Stand Delete, WOLO Airhorn.
The DEUCE is offline

post #4 of 9 (permalink) Old 04-18-2011, 10:31 PM
1985 VN-700

L2fish's Avatar

Join Date: Jun 2010
Location: Worcester, MA
Posts: 418
iTrader: (0)

Can batteries freeze?
L2fish is offline
post #5 of 9 (permalink) Old 04-18-2011, 10:52 PM
Concert connoisseur

wib714's Avatar

Join Date: Apr 2008
Location: chillicothe, ohio
Posts: 2,231
iTrader: (3)

Garage
Quote:
Originally Posted by L2fish View Post
Can batteries freeze?
if not the cold can surely damage them if not used in winter.

and to answer your questio, yes, fully charge it andhave them load test it, if its bad buy an agm maintenance free battery and not a wet cell like the original, its well worth the extra 20 - 30 dollars. pick up a small tube of dielectric grease for all your connections too!

1986 vn 750 aka "Huck Farley"
42,000 miles
Rick's stator and rr
Tuxedo stator cover mod
pickup coil mod
dampers replaced
agm m/f battery
Harley sportster exhaust, degoated
Hid conversion
splines lubed
custom "vn750.com" grill cover
NGK Iridium spark plugs


acct to mcct mod https://www.vn750.com/forum/showthread.php?t=17917

rekeying locks, https://www.vn750.com/forum/showthread.php?t=7309

stator replacement walkthrough, https://www.vn750.com/forum/showthread.php?t=11369
wib714 is offline
post #6 of 9 (permalink) Old 04-19-2011, 07:43 PM Thread Starter
Junior Member

Join Date: Apr 2011
Location: Foley AL
Posts: 20
iTrader: (0)

Thanks , I'm going to charge the battery this weekend and then get it tested.
slowz is offline
post #7 of 9 (permalink) Old 04-19-2011, 10:10 PM
1985 VN-700

L2fish's Avatar

Join Date: Jun 2010
Location: Worcester, MA
Posts: 418
iTrader: (0)

I think I may have ruined mine. I left it in the bike until january in an unheated shed in New England.
L2fish is offline
post #8 of 9 (permalink) Old 04-19-2011, 10:37 PM
Linkmeister Supreme

OlHossCanada's Avatar

Join Date: Aug 2008
Location: Lethbridge, Alberta, Canada
Posts: 7,960
iTrader: (8)

A less than fully charged batttery is more suseptible to freezing.

The vn750 battery is rated at 14 amp hours.
A battery should be charged at a rate of 10% of it`s capacicty, or 1.4 amps in this case.
The lowest rated automotive chargers are usually 2 amps, but that is close enough if you only leave it on for 4 or 5 hours.

Check the charging sysytem to be sure you are getting ~14.5 v at 5K rpm.
If the charging system is good, your battery is weak. Get a new MF-AGM battery. This is a good one:
http://cgi.ebay.com/ebaymotors/Deka-...item3eee173adb

Gordon

1991 VN 750 -"Cosmic Lady" or "Bad Girl"?
Purchased May 16, 2008
Approx.19,300km (12,000 miles)

H-D windshield
Relocated R/R
MF-AGM battery
Fiamm Freeway Blaster horns
F&S luggage rack and engine guard
Kury Offset Hiway pegs
July 13, 2016, Riding on the DARKSIDE now, Classic Radial 165/80-15


TOP TEN THINGS A NEW RIDER/OWNER SHOULD DO. Click on link.
https://www.vn750.com/forum/11-vn750-general-discussion/9127-top-ten-items-you-would-suggest-new-owner-do-his-new-ride.html

Last edited by OlHossCanada; 04-19-2011 at 10:42 PM.
OlHossCanada is offline
post #9 of 9 (permalink) Old 04-25-2011, 09:03 PM Thread Starter
Junior Member

Join Date: Apr 2011
Location: Foley AL
Posts: 20
iTrader: (0)

My battery tested fine, maybe I was just killing it trying to start the bike

Also the bike has alittle miss sometimes. So I pulled the plugs cleaned them up (were not bad) then was checking the plug wires and found this

This is where the plug wire goes into the coil. It looks like the end is missing, or is that how it should look?
